描述
The RLCS3257 is a single SPDT low on-resistance analog switch. It can operate from a single 1.5V to
5.5V power supply. The device offers low ON-state resistance and excellent ON-state resistance
matching with break-before-make feature, to prevent signal distortion during the transferring of a signal
from one channel to another. The device is capable of truly isolation. Even when A overrides VCC, very
little current will flow back to the supply.
Low On-resistance, Ron=1.5Ω when VA=5V
1.8V Logic Compatible Control Pin
VA Overrides VCC to Achieve True Isolation Even When Supply Is Dead
High Off-Isolation: -100dB @ 100KHz
Low Channel-to-Channel Crosstalk: -97dB @ 100KHz
High Bandwidth ( -3dB @700MHz) Suitable For USB2.0 High-Speed Routing
Low Quiescent Current (<2uA) With Very Wide Supply Range (1.5V ~ 5.5V)
DFN1109-6L Package
Audio
Video
UART, USB2.0 Signal and Supply Routing
Cell phones and TWS headset
