描述
The RLCS2750 is a dual SPDT low on-resistance analog switch. It can operate from a single 1.5V to 5.5V power
supply. The device offers low ON-state resistance and excellent ON-state resistance matching with breakbefore-make feature, to prevent signal distortion during the transferring of a signal from one channel to another. The device is capable of true isolation. Even when COMx overrides VCC, very little current will flow back to the supply.
Low On-resistance, Ron=1.5Ω when COMX=5V
1.8V Logic Compatible Control Pin
COMx Overrides VCC to Achieve True Isolation Even When Supply Is Dead
High Off-Isolation: -100dB @ 100KHz
Low Channel-to-Channel Crosstalk: -97dB @ 100KHz
High Bandwidth ( -3dB @700MHz) Suitable For USB2.0 High-Speed Routing
Low Quiescent Current (<2uA) With Very Wide Supply Range (1.5V ~ 5.5V)
TQFN-1.4x1.8-10L Package
Audio
Video
UART, USB2.0 Signal and Supply Routing
Cell phones and TWS headset
USB Type-C Mic/Gnd Switch
DC Motor Drive
