描述
The RLCS3157 is a single SPDT low on-resistance analog switch. It can operate from a single 1.5V
to 5.5V power supply. The device offers low ON-state resistance and excellent ON-state resistance
matching with break-before-make feature, to prevent signal distortion during the transferring of a
signal from one channel to another. The device is capable of truly isolation. Even when A overrides
VCC, very little current will flow back to the supply.
Very Wide Supply Range (1.5V ~ 5.5V)
Low Quiescent Current(<2uA)
Low On-resistance, Ron=1.5Ω when VA=5V
High Bandwidth(-3dB@700MHz) Suitable for USB2.0 High-Speed Routing
VA Overrides VCC to Achieve True Isolation Even When SupplyIs Dead
High Off-Isolation:-100dB@100KHz
Low Channel-to-Channel Crosstalk:-97dB@100KHz
ESD HBM:±5500V
SC70-6 Package
Audio
Video
UART,USB2.0 Signal and Supply Routing
Cell phone sand TWS head set
